MV Current Transformer Indoor Voltage Transformer SINGLE PHASE OPERATION POWER SUPPLY High Electrical Efficiency

Name: MV Current Transformer Indoor Voltage Transformer SINGLE PHASE OPERATION POWER SUPPLY High Electrical Efficiency
Brand: CY-Group
Price: 1 USD

Quality MV Current Transformer Indoor Voltage Transformer SINGLE PHASE OPERATION POWER SUPPLY High Electrical Efficiency wholesale

Brand Name : CY-Group

Model Number : DC-1/2/3-11

Certification : KEMA CE ISO SGS TUV UC3

Place of Origin : China

MOQ : 1pcs

Payment Terms : L/C, TT,D/A,D/P

Supply Ability : 3600000pcs/year

Delivery Time : 3-8 days

Packaging Details : Plymood

Material : Epoxy Resin

Voltage : 11KV

Rated Frequency : 50/60Hz

Installation site : Indoor

Rated primary voltage (kV) : 6.6 10 11KV

Technical standard : IEC60044-2 orIEC61869-1&3

Rated insulation level(kV) : 12/28/75

Phase Number : Single/Three

Contact Now

MV Current Transformer Indoor Voltage Transformer SINGLE PHASE OPERATION POWER SUPPLY High Electrical Efficiency

DC-1/2/3-11 voltage transformer , epoxy resin casting and double pole insulated fully enclosed construction, is used indoor for measuring current, electric energy and protective relaying in the electric system with the frequency 50Hz or 60Hz and highest voltage for equipment 12kV or single phase operation power supply.

The product has the feature of high reliability, low magnetism of core, large creepage distance of external insulation and maintenance free etc.

Main Parameter

1. Rated primary voltage: 11 kV etc

2. Technical standard accords with IEC 60044-2:2003 Part2 Instrument transformers-Part2: inductive voltage transformers or newest IEC standard IEC61869-3

Type	Rated primary voltage (kV)	Rated secondary voltage (kV)	Accuracy classes combination	Rated output (VA)	Thermal limiting current (VA)	Rated insulation level(kV)
DC-1-11	6.6 10 11	0.22	6P	1000	1000	12/28/75
DC-2-11		0.11/0.22 0.1/0.22	0.2/6P	30/2000	2000
DC-3-11		0.22	6P	3000	3000
DC-3-11		0.11/0.22 0.1/0.22	0.2/6P	30/3000	3000
